Technical parameters: |
Product features: |
-
The UV lamp: 2.0 kw * 1
-
UV lamp length: 460 mm, arc length: 350 mm
-
UV main peaks: 365 mm
-
Touch screen man-machine interface control
-
Light section emphasizes: 20% ~ 100% (adjusted)
-
Effective irradiation:350mm
-
Sheet metal light-box installation import insert reflector
-
Conveyor speed: 0 ~ 6 m/min (servo motor control)
-
Conveyor width:130mm
-
Conveying material: stainless steel mesh belt(SUS304)
-
Height: 100 mm (electric hoist light box height)
-
Power supply: 200 v/AC 50 hz
|
-
Optional configuration, can be customized according to customer's requirements
|
Remarks: all the UV machine can be made according to customer request non-standard, welcome to negotiate advisory!
|
Control system matching
|
|
Ordinary button control |
The man-machine interface |
|
UV lamp matching
|
|
Domestic UV lamp, mercury lamp, halogen lamp, etc.) |
Import UV lamp, mercury lamp, halogen lamp, etc.) |
|
Transformer selection (not detailed, welcome to inquire)
|
|
Copper wire |
aluminum steel |
|
Conveyor belt selection
|
|
Stainless steel mesh belt
|
Wangdai
|
Roller conveyor |
|
PCB special conveyor chain
|
Roller conveyor
|
PVC conveyor belt |
|
Non-standard custom delivery system
|
|
|
|
Cooling system matching
|
|
Air cooling
|
refrigeration
|
water-cooling
|
|
